Outdoor Ice Merchandisers

Outdoor Model 64

Interior Capacity: 170 7 lb. Bags | 65 20 lb. Bags
Dimensions (W" x D" x H"): 64 x 35.5 x 76.5

An everyday-capacity outdoor ice merchandiser with a narrower, deeper cabinet for reliable packaged ice storage.

Models & Cooling Types
Cooling Types
Model Number
Auto Defrost
L064UASP
Cold Wall
L064UCSP
Exterior Dimensions (WxDxH)
64 x 35.5 x 76.5
Interior Capacity
65 Cubic Feet
Door Opening (Wx H)
27 x 46
Bag Size
Auto Defrost
Cold Wall
7 lb. Bags
170
190
20 lb. Bags
65
70
Operating Temperature
16°F - 24°F
Refrigerant
R290
Compressor HP
1/2
Product Weight
Auto Defrost (lbs.)
430
Cold Wall (lbs.)
405
Standard Voltage (V/Hz)
115 / 60
Alternate Voltage
230V/50Hz (Available Upon Request)
Min. Circuit Required (Amps)
15 amps
Cooling Type
Amps
Auto Defrost
10
Cold Wall
10
DOE Compliant
Yes
CARB Compliant
Upon Request
NSF
Upon Request
Certifications
UL, cUL, CE

Outdoor Model 64

Is this model right for me?

The Outdoor Model 64 offers a narrower, deeper cabinet than the Outdoor Model 60 while maintaining similar packaged ice capacity. It’s a strong fit for exterior locations where width is limited but everyday ice sales still require dependable storage. Compared to the Outdoor Model 65, which shares the same exterior dimensions, the Model 64 adds a second customer access door and a stronger refrigeration package for locations where access and frequent customer use are priorities.

Best For

  • Outdoor locations that need strong packaged ice capacity in a narrower, deeper cabinet
  • Spaces where width is limited but everyday ice sales still require dependable storage
  • Two-door customer access in busier exterior merchandising areas
  • Convenience stores, liquor stores, grocery stores, and retail locations with steady packaged ice demand
  • Locations where frequent customer access is expected
  • Businesses that want outdoor ice storage built with R290 refrigerant and long-term compliance in mind

Outdoor Model 64

Videos

Learn more about Leer Outdoor Ice Merchandisers construction, and cooling types.

From Factory Floor to the Front of the Store – How An Ice Merchandiser is Made!

Outdoor Ice Merchandiser Overview

Outdoor Model 64

Product Literature

Spec sheets, warranty information, certifications, and other documents to help review or specify this model.

Outdoor Model 64

Support Documents

Maintenance guides, refrigerant information, troubleshooting resources, and other materials that support long-term operation.

Outdoor Model 64

Drawings

View dimensional drawings for footprint, door opening, and placement planning.
